Long-lasting non-directional pattern design contributes to efficient fuel consumption and guarantees operating comfort
Special crane compound help offer shorter braking distance and longer tyre life
DOT/ECE Certificated
| Tire Size | Type | LI/SS | Star Rating | TRA Code or Application | Recommended Rim/Flange Height | Approximate Inflated Dimensions | OTD | Cold Inflation Pressure | Max. Load Capacity | Application Max.Speed | ||||||||
| OD | SW | SLR | ||||||||||||||||
| inch | mm | inch | mm | inch | mm | inch | mm | 32ND | KPa | Psi | Kg | Lbs | km/h | |||||
| 385/95R25 | TL | 170F | ★★★ | - | 10.00/1.5 | 1369 | 53.9 | 379 | 14.9 | 626 | 24.6 | 25 | 31 | 900 | 131 | 6000 | 13200 | 80 |
| 445/95R25 | TL | 177F | ★★★ | - | 11.25/2.0 | 1481 | 58.3 | 435 | 17.1 | 695 | 27.4 | 26 | 33 | 900 | 131 | 7300 | 16100 | 80 |
| 525/80R20.5 | TL | 176F | ★★★ | - | 17.00/2.0 | 1488 | 58.6 | 518 | 20.4 | 697 | 26.9 | 28.5 | 35 | 700 | 102 | 7100 | 15700 | 80 |
*Reserves the rights of final interpretation and modification
