Super tread resists all kinds of cuts and impacts
Designed for excellence traction in moderate to severe conditions without compromising tread life
Multiple star constrction for heavy duty performance
| Tire Size | Type | LI/SS | Star Rating | TRA Code or Application | Recommended Rim/Flange Height | Approximate Inflated Dimensions | OTD | Cold Inflation Pressure | Max. Load Capacity | Application Max.Speed | ||||||||
| OD | SW | SLR | ||||||||||||||||
| inch | mm | inch | mm | inch | mm | inch | mm | 32ND | KPa | Psi | Kg | Lbs | km/h | |||||
| 26.5R25 | TL | 193B | ★★ | E-4 | 22.00/3.0 | 1750 | 68.9 | 675 | 26.6 | - | - | 56 | 71 | 525 | 76 | 11500 | 25400 | 50 |
| 29.5R25 | TL | 200B | ★★ | E-4 | 25.00/3.5 | 1875 | 73.8 | 750 | 29.5 | - | - | 66 | 83 | 525 | 76 | 14000 | 30900 | 50 |
| 29.5R29 | TL | 202B | ★★ | E-4 | 25.00/3.5 | 2025 | 79.7 | 750 | 29.5 | 843 | 33.2 | 61 | 77 | 525 | 76 | 15000 | 33100 | 50 |
| 35/65R33 | TL | 207B | ★★ | E-4 | 28.00/3.5 | 2030 | 79.9 | 890 | 34.3 | 924 | 36.4 | 63 | 79 | 475 | 69 | 17500 | 38580 | 50 |
*Reserves the rights of final interpretation and modification
